Auxiliary Control Panel for Triaxial / Permeability Tests

The HM-350A Auxiliary Control Panel allows operators to add supplementary triaxial or permeability test cells for increased productivity. The Auxiliary Panel attaches to the Master Control Panel and uses its digital pressure readout to display the confining and cell pressures. The Auxiliary Panel includes the identical precision regulators, valves, and reservoir and burette assemblies as the Master Control Panel, but does not include a Digital Pressure Gauge. Two HMA-350A Auxiliary Control Panels can be connected to each HM-350M Control Panel, allowing three samples to be tested simultaneously.

Features:

• Optimal for adding extra triaxial or permeability test cells, driving efficiency
• Effortlessly attaches to Master Control Panel for ease of operation

Included Items:

• Auxiliary Control Panel
• Connection tubing
• Two 50cc burettes graduated to 0.1cc
• Two 4cc pipettes graduated to 0.008cc

Accessories:

• Deairing Tanks are available with a 1.5 or 5.0gal tank capacity and is used to remove entrapped air from water while testing
• HMA-521 Pore Pressure Transducer with Digital Readout for precise measuring of soil specimen pore pressure
