150,000g Capacity Compact Field Scale, 50.0g Readability

Model: CP-150A
$278.0000
Price: $278.00

Compact Field Scales offer portable and affordable solutions for weighing concrete, soil and asphalt samples in remote locations.

Gilson’s digital models have sturdy steel bases, large stainless steel platforms and a wide range of capacities from 6 to 200kg (13 to 440lb) for fast, accurate weight determinations. Sturdy, foam-fitted carrying cases make all models easily transportable.

A hold function allows the operator to lock the weight reading on the display for convenience. The large stainless steel platform paired with the sturdy steel base adds stability when weighing large samples and is easy to clean. Remote mountable indicators display information in large LCD characters. The user can adjust weighing units between lb, kg, oz or lb: oz to suit unique application needs. Base dimensions are 11.8x11.8x2in (300x300x50mm).

All models meet ASTM C 29, C 138 and AASHTO T 19, T 121 concrete specifications when paired with Cast Aluminum unit weight measures or Air Meter bases, and the CP-75 is ideal for the most commonly used 0.25ft³ (7.08L) unit weight containers. They also feature a full capacity tare range and operate on six AA batteries or the included AC adapter.

Features:

  • Portable, affordable solution for field weights of soil, concrete and asphalt
  • kg, lb, oz, lb:oz selectable weighing units
  • Large, easy-to-read LCD display
  • Compliant with ASTM C29, C138 and AASHTO T 19 and T 121 for field unit weights and yield tests
  • Hold function allows continuous display of weight readings

Included Items:

  • Gilson Compact Field Scale
  • AC Adapter
  • RS-232 interface
  • Aluminum carrying case with fitted foam interior
  • Wall Mount Bracket
  • 1-year warranty
Capacity 150,000g (330lb)
Readability 50.0g
Repeatability 50.0g
Selectable Weighing Units kg, lb, oz, and lb:oz
Weigh-Below Option No
Display LCD
Power Requirements AC Adapter
Communication Port(s) RS-232 interface
Platform Size 11.8 x 11.8in (300 x 300mm), WxD
Outside Dimensions Including Case: 18.63 x 14.25 x 6in (473.08 x 361.95 x 152.4mm), WxDxH
Product Dimensions 11.8 x 11.8 x 2in (300 x 300 x 50mm), WxDxH
Estimated Shipping Weight 21.0lb (9.53kg)

Enter your name, email, and questions below and we will reply during business hours (8am - 5pm EST, Monday through Friday).

Capacity 150,000g (330lb)
Readability 50.0g
Repeatability 50.0g
Selectable Weighing Units kg, lb, oz, and lb:oz
Weigh-Below Option No
Display LCD
Power Requirements AC Adapter
Communication Port(s) RS-232 interface
Platform Size 11.8 x 11.8in (300 x 300mm), WxD
Outside Dimensions Including Case: 18.63 x 14.25 x 6in (473.08 x 361.95 x 152.4mm), WxDxH
Product Dimensions 11.8 x 11.8 x 2in (300 x 300 x 50mm), WxDxH
Estimated Shipping Weight 21.0lb (9.53kg)
