Soil Dispersion Mixer

Soil Dispersion Mixer (115V, 60Hz)

Soil Dispersion Mixer (115V, 60Hz)

Model: SA-14
$553.0000
Price: $553.00
Soil Dispersion Mixer (230V, 50/60Hz)

Soil Dispersion Mixer (230V, 50/60Hz)

Model: SA-14F
$564.0000
Price: $564.00

Soil Dispersion Mixer for hydrometer analysis of soil provides thorough mixing of soil samples using a special mixing blade and a baffled dispersion cup.

This product features a powerful 1/3hp motor that has selectable 13,000, 16,000, and 18,000rpm speeds, plus a manual pulse switch. The heavy die-cast aluminum housing and durable spindle are built to last under repeated use.

The dispersion mixer set includes a stainless steel dispersion cup with four sets of internal baffles as specified in the test methods. Additional SA-16 Dispersion Cups are available separately to enhance sample preparation efficiency.

Features:

  • The durable, long-lasting commercial-grade mixing unit
  • Meets all requirements of ASTM and AASHTO test methods

Included Items:

  • Soil Dispersion Mixer (115V, 60Hz or 230V, 50/60Hz)
  • Baffled Dispersion Cup

Accessories:

Related blogs:

Motor 1/3hp
Revolutions per Minute 13,000, 16,000, and 18,000rpm speeds
Electrical 115V/60Hz, 7.5 Amps or 230V/50-60Hz, 1.3 Amps
Product Dimensions 6.5 x 6.75 x 20.5in (165 x 171 x 521mm) WxDxH
Estimated Shipping Weight 17.0lb (7.71kg)

Enter your name, email, and questions below and we will reply during business hours (8am - 5pm EST, Monday through Friday).

Motor 1/3hp
Revolutions per Minute 13,000, 16,000, and 18,000rpm speeds
Electrical 115V/60Hz, 7.5 Amps or 230V/50-60Hz, 1.3 Amps
Product Dimensions 6.5 x 6.75 x 20.5in (165 x 171 x 521mm) WxDxH
Estimated Shipping Weight 17.0lb (7.71kg)
Meets Standard(s):
