Magnetic Gauge Holder for Dial Indicators

Model: HMA-338
$82.0000
Price: $82.00

HM-338 Magnetic Gauge Holder for Dial Indicators consists of a holder base with mounting rod and swivel adapter with yoke, and is used to secure mechanical and digital dial indicators to ferrous metal surfaces. The stainless steel rod is 6x0.25in (152x6.3mm) LxDia and is set in a ball socket fixture, allowing for universal positioning. The holder base has a strong magnetic pull of more than 55lbs, and is 1.125x3.5x1in (29x89x25mm) WxDxH. The 3in (76mm) long lug-back swivel adapter has a gun-metal finish, and attaches to the .25in rod with the included shoulder screw.

Features:

  • Provides universal positioning of dial indicators
  • Powerful magnetic pull
  • Stainless steel rod

Included Items:

  • Magnetic Gauge Holder for Dial Indicators
Dimensions Base: 1.125 x 3.5 x 1in (29 x 89 x 25mm) WxDxH, Rod: 0.25 x 6in (6.3 x 152mm) Dia.xL
Length Swivel Adapter: 3in (76mm)
Estimated Shipping Weight 1.0lbs (0.45kg)

Enter your name, email, and questions below and we will reply during business hours (8am - 5pm EST, Monday through Friday).

Dimensions Base: 1.125 x 3.5 x 1in (29 x 89 x 25mm) WxDxH, Rod: 0.25 x 6in (6.3 x 152mm) Dia.xL
Length Swivel Adapter: 3in (76mm)
Estimated Shipping Weight 1.0lbs (0.45kg)
