Type K Thermocouple Probes are the most common general-purpose thermocouple type. They all are immersible and have a standard yellow type k wire and two-blade male connector for use with many digital thermometers in general or specialized applications.
All probe models (except MAA-291 and HMA-320) have an immersible stainless steel probe with a sensitivity of approximately 41 µV/°C. The MAA-291 has a beaded wire for rapid results in difficult access areas. The HMA-320 probe has an immersible soldered wire tip.
MAA-286 Type K Thermocouple Probe has a temperature range of -58–572°F (-50–300°C) with an accuracy of ±0.75%. Thermocouple has a handle length of 4.5in (114mm) with probe dimensions of 4x0.08in (102x2mm), LxDia. and a 40in (1,016mm) long cord.
MAA-287 Type K Thermocouple Probe has a temperature range of -58–752°F (-50–400°C) with an accuracy of ±0.75%. Thermocouple has a handle length of 5.2in (133mm) with probe dimensions of 6x0.12in (152x3mm), LxDia., and a 40in (1,016mm) long cord.
MAA-288 Type K Thermocouple High-Temperature Probe has a temperature range of -58–1652°F (-50–900°C) with an accuracy of ±1.5°C at -40–375°C and ±0.4% at 376–1,050°C. Thermocouple has a handle length of 4in (105mm) with probe dimensions of 3.3x0.31in (83x8mm), LxDia., and a 46in (1,168.4mm) long cord.
MAA-290 Type K Thermocouple Probe has a temperature range of -58–752°F (-50–400°C) with an accuracy of ±0.4%. Thermocouple has a handle length of 4.5in (114mm) with probe dimensions of 4x0.11in (101.6x3mm), LxDia. and a 53in (1,346.2mm) long cord.
MAA-291 Type K Thermocouple Wire Probe has a temperature range of -58–572°F (-50–300°C) with a soldered wire tip. and a 47in (1,193.8mm) long immersible wire.
HMA-320 Type K Thermocouple Wire Probe has a temperature range of -328–400°F (-200–205°C) with a fast response wire tip and a 36in (914mm) long immersible wire.
| Model No. | Temperature
Range | Accuracy | Sensitivity | Handle
Length | Probe
Dimensions
LxDia. | Cord
Length |
|---|
| MAA-286 |
-58–572°F
(-50–300°C) |
±0.75% |
41 µV/°C |
4.5in
(114mm) |
4x0.08in
(102x2mm) |
40in
(1,016mm) |
| MAA-287 |
-58–752°F
(-50–400°C) |
±0.75% |
41 µV/°C |
5.2in
(133mm) |
6x0.12in
(152x3mm) |
40in
(1,016mm) |
| MAA-288 |
-58–1,652°F
(-50–900°C) |
±1.5°C at -40–375°C, ±0.4% at 376–1,050°C |
41 µV/°C |
4.0in
(105mm) |
3.3x0.31in
(83x8mm) |
46in
(1,168.4mm) |
| MAA-290 |
-58–752°F
(-50–400°C) |
±0.4% |
41 µV/°C |
4.5in
(114mm) |
4x0.11in
(101.6x3mm) |
53in
(1,346.2mm) |
| MAA-291 |
-58–572°F
(-50–300°C) |
— |
— |
— |
— |
47in
(1,193.8mm) |
| HMA-320 |
-328–400°F
(-200–205°C) |
— |
— |
— |
— |
36in
(914mm) |
Features:
- For use in general or specialized applications
- Immersible
- Two-blade male connector
Included Items:
- Type K Thermocouple Probe
