3" Sieve, Brass/Stainless, Half Height, No. 170 Mesh

Model: V3CH #170
More Information
$37.4000
Price: $37.40

3in (76mm) diameter ASTM E11 Test Sieve has stainless steel woven-wire cloth with No.170 (90µm) openings and half height brass frame. Each sieve is individually serial numbered. Overall height is 1-1/4in and stacked height is 5/8in.

Features:

  • Individually serial numbered
  • Compliant with ASTM E11 requirements for Compliance Sieves

Included Items:

  • 3” Sieve, Brass/Stainless, Half Height, No. 170 Mesh
  • Certificate of Conformance to ASTM E11 requirements

Optional Accessories:

  • Sieve Pans nest underneath sieves to collect fines
  • Sieve Covers prevent sample loss during agitation
  • Verification Services provide NIST traceable documentation of opening sizes
Sieve Frame Diameter 3in (76mm)
Frame Height Half Height
Stacked Frame Height 5/8in
Overall Frame Height 1-1/4in
Material Brass Frame / Stainless Steel Mesh
ASTM E11 Opening Size No.170 (90µm)
Backing Cloth Included No
Estimated Shipping Weight, lb (kg) 2.0lbs / 0.91kg
